1.2.5 Camera Cable/Camera Extension Cable
Camera Cable
Camera cable for Double speed random camera: ANM84303(CE), ANM84603
Camera cable for Ultra small camera: ANM842XX
No. Name Description
1 Connector (round, male) Connects a male connector to PV310.
2 Connector (round, female)
Connects a female connector to a camera.
(ANM842XX connects DC IN/VIDEO OUT port of the camera control unit for
an ultra compact camera.)
Camera Extension Cable
ANM840XXA (CE), ANM845XX
No. Name Description
1 Connector (round, male) Connects a male connector to PV310.
2 Connector (round, female)
Connects a female connector to a camera cable.
The connector is designated to connect with a camera cable, not for with a
connector of a camera.
