Panasonic Micro-Imagechecker PV310 - Index

352
INDEX
INDEX
A
Adjustment amount .......................................140
Arctangent.....................................................172
Area size adjustment .........................................85
Automatic switch mode .........................209, 212
Average range...............................................104
AXTOOL..........................................................44
B
Binary image ...................................................64
C
Calendar........................................................309
Camera control unit...........................................8
Camera head ....................................................7
Camera mode .................................................57
Cause of error signal.....................................316
Change IP address........................................310
Checker
Copy checker...............................................74
Types of checkers..................................64, 70
Checker applications.......................................70
Circuit
Input circuit ..................................................36
Output circuit................................................32
Compact flash
Backup image ............................................300
Restore setting data...........................256, 264
Computer link
Notes .........................................................284
Output example .........................................285
Supported PLCs ........................................283
Connection with PLC
Paralel I/O....................................................32
Serial （RS-232C) ......................................40
Contour Matching..........................................125
Conditions of use .......................................126
Conversion into actual value .........................178
Correlation.............................................114, 126
Cosine...........................................................172
Cutting dimensions......................................... 19
D
Numerical Calculation ...................................169
Data monitor
Alignment...................................................197
Number of rows and columns ....................196
Dislay image switch........................................ 53
Display image switch
Parallel I/O .................................................252
Serial command.........................................281
Drawing inspection area................................. 49
E
Edge extraction .............................................. 78
Edge threshold ..............................................102
Execute all mode...................................209, 211
Execution mode ......................................67, 209
F
Field mode ..................................................... 58
Filter ............................................................... 98
Flash output terminals .................................... 34
Flaw Detection ..............................................129
Frame mode................................................... 58
G
Gounding......................................................... 31
Gray cut.......................................................... 77
Group move ..........................................200, 204
H
Hold (Reset Condition)..................................248
