316
Troubleshootin
Cha
ter 15
15.1 ERROR Signal Is Output
If ERROR (error) signal is output from the parallel terminal (the ERROR lamp of the PV310 is on), the last
inspection was not properly executed or product type switch was not completed successfully. In this case, please
check the causes in the following table to adjust settings.
Problem: ERROR (error) signal is output during inspection*
*While executing inspection by inputting START signal and sending serial command
Cause
Relevant
Function
Error
Code
Check and Response
Values exceeded the following ranges
during calculation
• Effective range of values during
calculation
= -2147483648 to +2147483647 (- 2
31
to
(2
31
– 1))
• Effective range of values during
calculation of operator “square root”
= 0 to 461239364
Numeric
calculation
Denominator became “0” when the division
that is specified as a numeric calculation is
performed.
Numeric
calculation
E0161 The text “ER” is displayed in the
calculation result field.
Numeric
calculation
E0161
Judgment E0162
Statistics E0163
• The text “ER” is displayed in the
result display area of Numeric
Calculation, Judgment and
Statistics windows.
Any item that does not exist is referred to
the Numeric calculation, Judgment,
Statistics, and Data Monitor windows. (If
the quoted item is deleted.)
Data Monitor E0164
• The text “ER” is displayed in some
cells in the Data Monitor window in
RUN mode.
Processing time of Smart Matching
exceeds 10 seconds
Smart Matching E0102 Adjust the condition to shorten the
processing time.
Example) Larger value of search
starting accuracy in the search
sequence:
A change of the current value, “4” to
“8”.
RS-232C
Computer Link
mode
E0166
Parallel
Handshake
E0165
As the setting timeout value is
changed, inspection time synchronizes
and changes.
Timeout value (default setting: 5000
ms) can be changed by selecting
“ENVIRONMENT”>”Data Output
Settings” > “General Output” tab.
Communication Timeout Error
Image output
through Ethernet
E0167 In case of a communication error
continued over 15 seconds when
outputting error signal is set.
*About setting error signal output, refer
to page 237.
To Next Page
