317
Cha
ter 15
Troubleshootin
Cause
Relevant
Function
Error
Code
Check and Response
Camera capturing error
• Connects a normal camera: ANM832 and sets D.S.Random
Frame/Field mode.
• The DIP switch setting of a D.S. Random camera does not
correspond with the camera mode selected with PV310.
E.g.)
Camera mode: D.S. Random Frame
DIP switch setting: Field (No.6 = OFF)
• Connects a D.S. Random camera to Camera port B.
• Connects a D.S. Random camera with a camera cable
incorrectly or a cable disconnected.
E0071 Connect and set correctly. If the error
reoccurs, try the following procedures.
• Cut the power and reconnect the
camera cable.
• Replace the cable.
Problem: ERROR (error) signal is output while inspection is not performed.
Timing
Error
Code
Cause
When data saving E0170 When PV310 failed to save data by serial command input
and returned error response “%Z” to the external device.
When product types were switched E0171 Product types were switched by specifying the number of
the product type that has not been created.
When display images were switched E0172
When the data of CF card was restored. E0173
When a template was re-registered E0174
By using parallel (I/O) signal
Execution signal (FCT1/FCT2) was input by specifying an
undefined combination of IN1-IN3 or IN1 –IN7 signals.
By using serial command
When each command was input, the PV310 returned error
response “%Z” to the external device.
When changing the binary slice level E0175
When referring Gray Edge threshold value E0176
When changing Gray Edge threshold
value
E0177
When referring numerical calculation
maximum/minimum value
E0178
When changing numerical calculation
maximum/minimum value
E0179
When serial command was input, the PV310 returned error
response “%Z” to the external device.
For more information, refer to Chapter 11.2.6 “Details of
Commands”.
During AXTOOL communication E0180 More than 30 seconds has passed since communication the
PV310 and external device was disconnected by removing
the Ethernet cable while the PV310 was communicating with
AXTOOL. Ver. 3.
To Next Page
