10.1.3 Data Assignment for Handshake
Output of judgment results
If “Handshake” is set to “No”, the signals JD01 to 08 signals are output to the terminals D1 to D8.
Judgment results including the last number are output in 8-bit form. But, if the PV310 is in User-Defined mode
and Automatic Switch mode, only the judgment formulas of the executed block and only the Judgment formulas
of block 2 or 3 are output respectively.
1st.
D8 D7 D6 D5 D4 D3 D2 D1
JD08 JD07 JD06 JD05 JD04 JD03 JD02 JD01
2nd.
D8 D7 D6 D5 D4 D3 D2 D1
JD16 JD15 JD14 JD13 JD12 JD11 JD10 JD09
・
・
12th ・
D8 D7 D6 D5 D4 D3 D2 D1
JD96 JD95 JD94 JD93 JD92 JD91 JD90 JD89
Data output of Number of scans, Numeric Calculation
The data of the number of scans and Numeric Calculation are assigned according to the setting value for “Data
Type” as the tables shown below. The data of items that are set not to output are skipped (not output).
Output Data: 8 bits
D8 D7 D6 D5 D4 D3 D2 D1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Output Data: 16 bits
1st.
D8 D7 D6 D5 D4 D3 D2 D1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2nd.
D8 D7 D6 D5 D4 D3 D2 D1
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
Output Data: 32 bits
1st.
D8 D7 D6 D5 D4 D3 D2 D1
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
2nd.
D8 D7 D6 D5 D4 D3 D2 D1
Bit 15 Bit 14 Bit 13 Bit 12 Bit 11 Bit 10 Bit 9 Bit 8
3rd.
D8 D7 D6 D5 D4 D3 D2 D1
Bit 23 Bit 22 Bit 21 Bit 20 Bit 19 Bit 18 Bit 17 Bit 16
4th
D8 D7 D6 D5 D4 D3 D2 D1
Bit 31 Bit 30 Bit 29 Bit 28 Bit 27 Bit 26 Bit 25 Bit 24
