Procedure for Settin

Ins

ection Conditions

Cha

ter 5

5.8 Executing Inspection

5.8.1 Procedure for Inspection Execution

Execute inspection according to your settings.

1. Switch to RUN mode.

Keep pressing the C key until the menu bar disappears.

2. Press the A key.

Inspection is started, and the total judgment results or status of the signal output from terminal block are

displayed in the status display area at the left side of the monitor screen. At this time, even if START signal

is input or the serial commands for inspection are sent from the external device, the total judgment result or

the output status of the signal is displayed in the status display area.
