261
Cha
p
ter 11
RS-232C Communication
Unused Digits
If “Unused Digits” are set to “Comma separated”, only the data of unused digits are output. Commas are inserted
into the data for separation. If “Filled with '0'” is selected, unused digits are filled with '0'.
Output format of Judgment data:
Number of Digits Always 1-digit output data
Regardless of the digit number of output, 1-digital data are output per judgment.
Number of Data Up to 96
Values To Be Output OK = 1, NG = 0, Error=E and None = no value output
Output format of Scans, Numeric Calculation and Statistics data:
Number of Digits Variables 1 digit - 11 digits
Depending on the number of Output Digits or Unused digits
Number of Data Scans: only one, Up to 96 data for Numeric Calculation and Statistics
Value To Be Output Normal = - 2147483648 to + 2147483647
More than the specified output digits = 0
Error = 0
Unset = no value output
Example of Output
The following output results can be obtained for the same Data Conditions and different Output Conditions.
Data Conditions
Number of Scans = 1234
Judgment: JD01 = OK, JD02 = Unset, JD03 = NG
Numeric Calculation: CA01 = 215, CA02 = Unset, CA03 = -368
Statistics: QS01 = 13912
Output result
Output setting condition Output result
Output Digits: 4 and Unused
Digits: Filled with '0'
1 2 3 4 1 0 0 2 1 5 - 3 6 8 0 0 0 0 CR
Output Digits: 4 and Unused
Digits: Comma separated
1 2 3 4 , 1 , 0 , 2 1 5 , - 3 6 8 , 0 CR
Concept:
Judgment JD02 is not output, because Numeric Calculation CA02 is unset.
The value of statistics QS01 is 5 digits and it exceeds the specified output digits (four digits).
The order and format of output data are the same as the ones above regardless of output setting of Ethernet or
Computer Link.
