319
Cha
ter 15
Troubleshootin
Code Relative checker Problem Solution
E0077 Binary window
Gray window
Binary edge
Gray edge
Feature extraction
Flaw detection
When the Area Size
Adjustment function was
used, nothing was detected by
the reference checker.
Configure the settings of the Area Size Adjustment
function so that the checker registered as a reference
checker can detect an object or a target part.
E0101 Contour matching
Rotation
adjustment
(Contour)
Camera mode is set to a field
mode or the current memory
image has been captured in
field mode.
Camera mode is available only in D.S. Random
Frame, Normal Frame or Int. Sync Mode Frame.
When you are running a test with the restored images
on the Compact Flash memory card, use the images
captured in Frame mode.
To Next Page
