Chapter 4: Management with WebPAM PROe
137
Working with the Logical Drive Summary
The Logical Drive Summary displays a list of all logical drives in the VessRAID
enclosure plus the expanded or cascaded enclosures. This list does not arrange
the logical drives under the disk array to which they belong nor under the
enclosure in which they are located.
Logical Drive Summary includes the following functions:
• Viewing a List of All Logical Drives (page 137)
• Viewing Individual Logical Drive Information (page 137)
Viewing a List of All Logical Drives
To view a list of all logical drives in all enclosures:
1. Click the Subsystem icon in Tree View.
2. Click the Drive Summary icon.
Viewing Individual Logical Drive Information
1. Click the Subsystem icon in Tree View.
2. Click the Drive Summary icon.
3. Click the Logical Drive icon.
The information and location for the logical drive appear in Management
View. See Viewing Logical Drive Information (page 128).
