Chapter 2: VessRAID Installation
21
If you have another iSCSI VessRAID subsystem, configure its Management
Path in the same way.
Figure 13.SAN data and management connections
Host PCs or
Servers
Std. NIC
Std.
Network
Switch
GbE
Network
Switch
VessRAID
VessRAID
GbE NIC
Std. NIC
GbE NIC
Management Cables
Data Cables
iSCSI Data Ports
Management Port
