R&S
®
ZVA / R&S
®
ZVB / R&S
®
ZVT GUI Reference
Channel Menu
Operating Manual 1145.1084.12 – 30 259
characteristics in time:
Sweep time
The time interval between two consecutive trigger pulses must not be smaller than the minimum
measurement time for one measurement point described for Time sweeps.
In CW Mode sweep mode the Start, Center and Stop softkeys are inactive, still you can use the
START CENTER hardkey to select the fixed CW frequency.
[SENSe<Ch>:]SWEep:TYPE POINt
[SENSe<Chn>:]FUNCtion[:ON] "XTIMe:..."
SOURce<Ch>:FREQuency<Pt>:CW|FIXed
SOURce<Ch>:POWer[:LEVel][:IMMediate][:AMPlitude]
Define Segments
Opens a dialog to define all channel settings for a Segmented Frequency sweep and to import and export
segmented sweep settings.
The Define Segments dialog contains a table to edit the individual segments of the sweep range. Sweep
segments may have common points or even overlap; see Columns in the Define Segments table.
Below the table, three groups of controls provide additional settings. Refer to the following sections below:
