Example:
See [SENSe<Ch>:]SEGMent<Seg>:TRIGger:STATe
[SENSe<Ch>:]SEGMent<Seg>:TRIGger:STATe <Boolean>
Deactivates/activates triggering for segment <Seg>. This setting only takes effect if
1. the analyzer is not in Free Run mode (see TRIGger<Ch>[:SEQuence]:SOURce)
2. selective segment triggering is enabled ([SENSe<Ch>:]SEGMent<Seg>:TRIGger:CONTrol
ON)
<Ch>
Channel number
<Seg>
Sweep segment number
<Boolean>
ON: All triggers within the segment are active, except when
TRIGger<Ch>[:SEQuence]:LINK
is set to 'SWEep'.
OFF: All triggers within the segment are inactive, i.e. the segment will be
sweeped in one go - immediately after the previous segment.
*RST value
ON
SCPI, Command
Types
Device-specific, command or query
Example:
SEGM2:TRIG:STAT OFF
Deactivates triggering for segment 2.
SEGM2:TRIG:STAT?
Returns 0. However, this will not take effect unless selective segment triggering is
enabled.
SEGM:TRIG:CONT ON
Enables selective segment triggering
[SENSe<Ch>:]SWEep...
This subsystem provides general settings to control the sweep. Most of the settings have an impact on the
sweep time.
The [SENSe<Ch>:]SWEep... settings apply to non-segmented sweep types. Segmented sweeps are
selected via [SENSe<Ch>:]SWEep:TYPE SEGMent and configured in the
[SENSe<Ch>:]SEGMent<Seg>... subsystem.
[SENSe<Ch>:]SWEep:AXIS:FREQuency '<frequency_ref>'
Selects the stimulus signal that is used for the definition of the frequency sweep range or CW frequency.
