RL78/G1H CHAPTER 6 CLOCK GENERATOR
R01UH0575EJ0120 Rev. 1.20 Page 134 of 920
Dec 22, 2016
Table 6 - 7 CPU Clock Transition and SFR Register Setting Examples (5/5)
(11) • STOP mode (H) set while CPU is operating with high-speed on-chip oscillator clock (B)
• STOP mode (I) set while CPU is operating with high-speed system clock (C)
(12) CPU changing from STOP mode (H) to SNOOZE mode (J)
For details about the setting for switching from the STOP mode to the SNOOZE mode, see 13.8 SNOOZE Mode
Function, 14.5.7 Calculating transfer clock frequency, and 14.6.3 Calculating baud rate.
Remark (A) to (J) in Tables 6 - 3 to 6 - 7 correspond to (A) to (J) in Figure 6 - 19.
(Setting sequence)
Status Transition Setting
(B)
→ (H) Stopping peripheral
functions that cannot
operate in STOP mode
— Executing STOP
instruction
(C)
→ (I) In X1 oscillation Sets the OSTS register
External main
system clock
—
To Next Page
