RL78/G1H CHAPTER 14 SERIAL ARRAY UNIT

R01UH0575EJ0120 Rev. 1.20 Page 355 of 920

Dec 22, 2016

The channels supporting 3-wire serial I/O (CSIp) are channel 2 of SAU0 and channels 0 to 2 of SAU1.

Note CSI20 is used for internal communication between MCU and RF transceiver. For this channel, only the

master can be selected.

3-wire serial I/O (CSIp) performs the following seven types of communication operations.

• Master transmission (See 14.5.1.)

• Master reception (See 14.5.2.)

• Master transmission/reception (See 14.5.3.)

• Slave transmission (See 14.5.4.)

• Slave reception (See 14.5.5.)

• Slave transmission/reception (See 14.5.6.)

Unit Channel Used as CSI Used as UART

0 0 Cannot be used Cannot be used

2CSI10UART1

3 Cannot be used

CSI20

Note

Cannot be used

1CSI21

2CSI30UART3

3 Cannot be used
