<2>In the case of the Mode Switch frame
Figure 18 - 6 shows the PHR bit configuration in the case of the Mode Switch frame.
The respective PHR bits automatically capture the set value and transmit it to the corresponding
register.
Only the register values are transmitted on the hardware while no Checksum or Parity Check
function is included.
Figure 18 - 6 PHR Bit Configuration in the Case of the Mode Switch Frame
MS: Mode Switch
Mode switch enable bit value: Mode switch frame transmission register bit 0
Automatically transmits the following values when this bit value is 1.
M1, M0: Mode Switch Parameter Entry
Mode switch frame transmission register bits 1 and 2
FEC: New Mode FEC
Mode switch frame transmission register bit 3
New Mode: New Mode
Mode switch frame transmission register bits 4 to 10
B3 to B0: Checksum
Mode switch frame transmission register bits 11 to 14
PC: Parity Check
Mode switch frame transmission register bit 15
Bit array 0123456789101112131415
Bit configuration MS M1 M0 FEC New Mode B3 B2 B1 B0 PC
