RL78/G1H CHAPTER 18 RF TRANSCEIVER

R01UH0575EJ0120 Rev. 1.20 Page 572 of 920

Dec 22, 2016

Figure 18 - 13 Transmit/Receive Status Register 0 (BBTXRXST0) Format

Note Bits 0 to 3, 6, and 7 are Read Only.

Address:

0007H

After reset:

80H

R/W

Note

Symbol76543210

BBTXRXS

RCVRAMST RCVPEND RCVBANK1 RCVBANK0 TRNRCVSQC CSMACA CRC CCA

RCVRAMST Receive RAM bank pointer bit

0 Receive RAM bank 0

1 Receive RAM bank 1

RCVPEND Receive pending bit

0 No pending

1 Pending exists

RCVBANK1 Receive RAM bank 1 status bit

0 Receive enabled

1 Receive data exists

RCVBANK0 Receive RAM bank 0 status bit

0 Receive enabled

1 Receive data exists

TRNRCVSQC

Transmit/receive operation completion judge result bit

0OK

1NG

CSMACA CSMA-CA judge result bit

0OK

1NG

CRC CRC judge result bit

0OK

1NG

CCA CCA judge result bit

0 Channel clear

1 Channel busy
