Figure 18 - 15 Transmit/Receive Mode Register 3 (BBTXRXMODE3) Format
Address:
000AH
After reset:
00H
R/W
Symbol76543210
BBTXRX
MODE3
ADFGENMO
DE
ADFEXTEN RCVOVERW
REN
RCVBANKSEL LVLFILEN RXEN PANCORD ADRSFILEN
ADFGENMO
DE
Address filter general-purpose mode bit
0 The WiSUN mode
1 The general purpose mode
ADFEXTEN Address filter address extension bit
0 PANID&Address expansion disabled
1 PANID&Address expansion enabled
RCVOVERW
REN
Receive RAM overwrite enable bit
0 Overwrite disabled
1 Overwrite enabled
RCVBANKS
EL
Receive data bank select bit
0 Receive data bank 0
1 Receive data bank 1
LVLFILEN Receive level filter enable bit
0 Filter disabled
1 Filter enabled
RXEN Receive enable bit
0 Receive disable
1 Receive enable
PANCORD PAN coordinator bit
0 Not a PAN coordinator
1 PAN coordinator
ADRSFILEN Address filter enable bit
0 Address filter disabled
1 Address filter enabled
