RL78/G1H
CHAPTER 18 RF TRANSCEIVER
R01UH0575EJ0120
Rev
. 1.20
Page 660 of 920
Dec 22, 2016
T
able 18 - 14 Initial Setting Reg
isters
Register address (H)
Setting value (H)
000A
8C
003A
80
0048
04
0052
0E
0053
01
0054
5E
0057
50
0058
E6
005A
F0
005C
F0
0078
E6
007C
50
007E
E6
0086
03
008E
73
0092
7B
0094
26
0096
73
00A6
0F
0402
04
0430
02
043A
94
046F
05
0470
05
0473
F6
0475
32
047A
60
047B
01
047E
03
0481
00
0488
82
04EE
00
04F9
03
0501
10
050D
60
050E
01
050F
02
0510
00
0515
03
0583
7F
0587
7F
05A5
0A
05A6
0A
05AD
40
00D8
04
00D9
44
00DC
8D
00DD
1F
00DC
00
00DD
6E
