RL78/G1H CHAPTER 18 RF TRANSCEIVER

R01UH0575EJ0120 Rev. 1.20 Page 703 of 920

Dec 22, 2016

Note 1. Value saved to MCU address EFFECH.

Note 2. Value saved to MCU address EFFEDH.

Note 3. Value saved to MCU address EFFEEH.

Note 4. Value saved to MCU address EFFEFH.

Table 18 - 60 Settings Required for Each Data Rate (9/9)

Frequency

band

identifier

PHY Mode

Data

rate

(kbps)

Address (H)

00DC 00DD 00DC 00DD 00DC 00DD

4 863 MHz

(Europe)

001 50

Note 1

01H

Note 2

02H

Note 3

0BH

002 100

Note 1

01H

Note 2

02H

Note 3

0BH

003 200

Note 1

01H

Note 2

02H

Note 3

0BH

5 896 MHz

(US)

004 10

Note 1

01H

Note 2

02H

Note 3

0BH

005 20

Note 1

01H

Note 2

02H

Note 3

0BH

006 40

Note 1

01H

Note 2

02H

Note 3

0BH

6 901 MHz

(US)

007 10

Note 1

01H

Note 2

02H

Note 3

0BH

008 20

Note 1

01H

Note 2

02H

Note 3

0BH

009 40

Note 1

01H

Note 2

02H

Note 3

0BH

7 915 MHz

(US)

010 50

Note 1

01H

Note 2

02H

Note 3

0BH

011 150

Note 1

01H

Note 2

02H

Note 3

0BH

012 200

Note 1

01H

Note 2

02H

Note 3

0BH

8 917 MHz

(Korea)

013 50

Note 1

01H

Note 2

02H

Note 3

0BH

014 150

Note 1

01H

Note 2

02H

Note 3

0BH

015 200

Note 1

01H

Note 2

02H

Note 3

0BH

9 920 MHz

(Japan)

016 50

Note 1

01H

Note 2

02H

Note 3

0BH

000 100

Note 1

01H

Note 2

02H

Note 3

0BH

017 200

Note 1

01H

Note 2

02H

Note 4

0BH

018 400

Note 1

01H

Note 2

02H

Note 4

0BH

Other

019 300

Note 1

01H

Note 2

02H

Note 4

0BH

020 100

Note 1

01H

Note 2

02H

Note 3

0BH

021 300

Note 1

01H

Note 2

02H

Note 4

0BH
