RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 717 of 920
Dec 22, 2016
Figure 19 - 7 Format of Priority Specification Flag Registers (PR00L, PR00H, PR01L, PR01H, PR02L, PR02H,
PR10L, PR10H, PR11L, PR11H, PR12L, PR12H) (2/2)
Caution The available registers and bits differ depending on the product. For details about the registers and
bits available for each product, see Tables 19 - 3 to 19 - 5. Be sure to set bits that are not available to
the initial value.
Address: FFFEEH After reset: FFH R/W
Symbol <7> <6> <5> <4> <3> <2> <1> <0>
PR11L TMPR103 TMPR102 TMPR101 TMPR100 IICAPR10
SREPR11
TMPR103H
SRPR11
STPR11
CSIPR110
Address: FFFEBH After reset: FFH R/W
Symbol <7> <6> <5> <4> 3 <2> <1> <0>
PR01H TMPR010 TRJPR00 SRPR03
STPR03
CSIPR030
1 ITPR0 RTCPR0 ADPR0
Address: FFFEFH After reset: FFH R/W
Symbol <7> <6> <5> <4> 3 <2> <1> <0>
PR11H TMPR110 TRJPR10 SRPR13
STPR13
CSIPR130
1 ITPR1 RTCPR1 ADPR1
Address: FFFD8H After reset: FFH R/W
Symbol <7> <6> 5 <4> <3> <2> <1> <0>
PR02L PPR010 PPR09 1 PPR07 PPR06 TMPR013 TMPR012 TMPR011
Address: FFFDCH After reset: FFH R/W
Symbol <7> <6> 5 <4> <3> <2> <1> <0>
PR12L PPR110 PPR19 1 PPR17 PPR16 TMPR113 TMPR112 TMPR111
Address: FFFD9H After reset: FFH R/W
Symbol <7> <6> 5 <4> 3 2 1 <0>
PR02H FLPR0 IICAPR01 1
SREPR03
TMPR013H
1 1 1 PPR011
Address: FFFDDH After reset: FFH R/W
Symbol <7> <6> 5 <4> 3 2 1 <0>
PR12H FLPR1 IICAPR11 1
SREPR13
TMPR113H
1 1 1 PPR111
XXPR1X XXPR0X Priority level selection
0 0 Specify level 0 (high priority level)
0 1 Specify level 1
1 0 Specify level 2
1 1 Specify level 3 (low priority level)
