RL78/G1H CHAPTER 19 INTERRUPT FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 719 of 920
Dec 22, 2016
Table 19 - 6 shows the Ports Corresponding to EGPn and EGNn bits.
Table 19 - 6 Ports Corresponding to EGPn and EGNn bits
Caution When the input port pins used for the external interrupt functions are switched to the output mode, the INTPn
interrupt might be generated upon detection of a valid edge.
When switching the input port pins to the output mode, set the port mode register (PMxx) to 0 after disabling the
edge detection (by setting EGPn and EGNn to 0).
Remark 1.
For edge detection port, see 3.1 Port Functions.
Remark 2. n = 0 to 11
Detection Enable Bit Interrupt Request Signal
EGP0 EGN0 INTP0
EGP3 EGN3 INTP3
EGP4 EGN4 INTP4
EGP6 EGN6 INTP6
EGP7 EGN7 INTP7
EGP9 EGN9 INTP9
EGP10 EGN10 INTP10
EGP11 EGN11 INTP11
