RL78/G1H CHAPTER 24 SAFETY FUNCTIONS
R01UH0575EJ0120 Rev. 1.20 Page 790 of 920
Dec 22, 2016
24.3.7.1 Timer input select register 0 (TIS0)
The TIS0 register is used to select the timer input of channels 0 and 1 of the timer array unit 0 (TAU0).
The TIS0 register can be set by an 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 24 - 14 Format of Timer input select register 0 (TIS0)
Address: F0074H After reset: 00H R/W
Symbol76543210
TIS0 0 0 0 TIS04 0 TIS02 TIS01 TIS00
TIS04 Selection of timer input used with channel 0
0 No timer input
1 Event input signal from ELC
TIS02 TIS01 TIS00 Selection of timer input used with channel 1
0 0 0 No timer input
0 0 1 Event input signal from ELC
0 1 0 Setting prohibited
011
1 0 0 Low-speed on-chip oscillator clock (f
IL)
1 0 1 Subsystem clock (fSUB)
Other than above Setting prohibited
