RL78/G1H CHAPTER 4 CPU ARCHITECTURE

R01UH0575EJ0120 Rev. 1.20 Page 64 of 920

Dec 22, 2016

Table 4 - 14 Extended Special Function Register (2nd SFR) List (5/7)

Address

Extended Special Function Register

(2nd SFR) Name

Symbol R/W

Manipulable Bit Range

After Reset

1-bit 8-bit 16-bit

F01A6H Timer status register 03 TSR03L TSR03 R —

√√0000H

F01A7H — — —

F01B0H Timer channel enable status register

TE0L TE0 R

√√√0000H

F01B1H — — —

F01B2H Timer channel start register 0 TS0L TS0 R/W

√√√0000H

F01B3H — — —

F01B4H Timer channel stop register 0 TT0L TT0 R/W

√√√0000H

F01B5H — — —

F01B6H Timer clock select register 0 TPS0 R/W — —

√ 0000H

F01B7H

F01B8H Timer output register 0 TO0L TO0 R/W —

√√0000H

F01B9H — — —

F01BAH Timer output enable register 0 TOE0L TOE0 R/W

√√√0000H

F01BBH — — —

F01BCH Timer output level register 0 TOL0L TOL0 R/W —

√√0000H

F01BDH — — —

F01BEH Timer output mode register 0 TOM0L TOM0 R/W —

√√0000H

F01BFH — — —

F01C0H Timer counter register 10 TCR10 R — —

√ FFFFH

F01C1H

F01C2H Timer counter register 11 TCR11 R — —

√ FFFFH

F01C3H

F01C4H Timer counter register 12 TCR12 R — —

√ FFFFH

F01C5H

F01C6H Timer counter register 13 TCR13 R — —

√ FFFFH

F01C7H

F01D0H Timer mode register 10 TMR10 R/W — —

√ 0000H

F01D1H

F01D2H Timer mode register 11 TMR11 R/W — —

√ 0000H

F01D3H

F01D4H Timer mode register 12 TMR12 R/W — —

√ 0000H

F01D5H

F01D6H Timer mode register 13 TMR13 R/W — —

√ 0000H

F01D7H

F01E0H Timer status register 10 TSR10L TSR10 R/W —

√√0000H

F01E1H — — —

F01E2H Timer status register 11 TSR11L TSR11 R/W —

√√0000H

F01E3H — — —

F01E4H Timer status register 12 TSR12L TSR12 R/W —

√√0000H

F01E5H — — —
