RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 858 of 920
Dec 22, 2016
Note Connect the REGC pin to VSS via a capacitor (0.47 to 1 μF). This value regulates the absolute maximum rating of the
REGC pin. Do not use this pin with voltage applied to it.
Caution Product quality may suffer if the absolute maximum rating is exceeded even momentarily for any parameter.
That is, the absolute maximum ratings are rated values at which the product is on the verge of suffering physical
damage, and therefore the product must be used under conditions that ensure that the absolute maximum
ratings are not exceeded.
Remark Unless specified otherwise, the characteristics of alternate-function pins are the same as those of the port pins.
Absolute Maximum Ratings (2/2)
Parameter Symbols Conditions Ratings Unit
REGC pin input voltage V
IREGC REGC ‒0.3 to +2.8 and
‒0.3 to V
DD + 0.3
Note
V
RF power supply input V
REGIN REGIN ‒0.3 to +3.8 V
RF power supply output V
RFOUT1 DDCOUT ‒0.3 to +3.8 V
V
RFOUT2 VREGO1, VREGO2, VREGO3 ‒0.3 to +1.25 V
Output current, high I
OH1 Per pin P02 to P04, P31, P40, P70 to P72, P75 to P77,
P80 to P82, P100, P120, P130, P140 to P144
‒40 mA
Tota l o f all
pins
‒170 mA
P02 to P04, P40, P120, P130, P140 to P144 ‒70 mA
P31, P70 to P72, P75 to P77, P80 to P82, P100 ‒100 mA
I
OH2 Per pin P20 to P22, P155, P156 ‒0.5 mA
Tota l o f all
pins
‒2mA
I
OHRF Per pin GPIO0, GPIO1, GPIO2, GPIO3, GPIO4 ‒17 mA
Output current, low I
OL1 Per pin P02 to P04, P31, P40, P60 to P63, P70 to P72,
P75 to P77, P80 to P82, P100, P120, P130,
P140 to P144
40 mA
Tota l o f all
pins
170 mA
P02 to P04, P40, P120, P130, P140 to P144 70 mA
P31, P60 to P63, P70 to P72, P75 to P77,
P80 to P82, P100
100 mA
I
OL2 Per pin P20 to P22, P155, P156 1 mA
Tota l o f all
pins
5mA
I
OLRF Per pin GPIO0, GPIO1, GPIO2, GPIO3, GPIO4 17 mA
Operating ambient
temperature
T
A In normal operation mode ‒40 to +85 °C
In flash memory programming mode
Storage temperature T
stg ‒65 to +150 °C
