RL78/G1H CHAPTER 31 ELECTRICAL SPECIFICATIONS
R01UH0575EJ0120 Rev. 1.20 Page 861 of 920
Dec 22, 2016
Note 1. Value of current at which the device operation is guaranteed even if the current flows from an output pin to the VSS pin.
Note 2. Do not exceed the total current value.
Note 3. Specification under conditions where the duty factor ≤ 70%.
The output current value that has changed to the duty factor > 70% the duty ratio can be calculated with the following
expression (when changing the duty factor from 70% to n%).
• Total output current of pins = (I
OL × 0.7)/(n × 0.01)
<Example> Where n = 80% and I
OL = 10.0 mA
Total output current of pins = (10.0 × 0.7)/(80 × 0.01) ≈ 8.7 mA
However, the current that is allowed to flow into one pin does not vary depending on the duty factor.
A current higher than the absolute maximum rating must not flow into one pin.
Remark Unless specified otherwise, the characteristics of alternate-function pins are the same as those of the port pins.
(TA = ‒40 to +85 °C, 1.8 V ≤ VDD ≤ 3.6 V, VSS = 0 V) (2/5)
Items Symbol Conditions MIN. TYP. MAX. Unit
Output current, low
Note 1
IOL1 Per pin for P02 to P04, P31, P40,
P70 to P72, P75 to P77,
P80 to P82, P100, P120, P130,
P140 to P144
20.0
Note 2
mA
Per pin for P60 to P63 15.0
Note 2
mA
Total of P02 to P04, P40, P120,
P130, P140 to P144
(When duty ≤ 70%
Note 3
)
2.7 V ≤ V
DD ≤ 3.6 V 15.0 mA
1.8 V ≤ V
DD < 2.7 V 9.0 mA
Total of P31, P60 to P63,
P70 to P72, P75 to P77,
P80 to P82, P100
(When duty ≤ 70%
Note 3
)
2.7 V ≤ V
DD ≤ 3.6 V 35.0 mA
1.8 V ≤ V
DD < 2.7 V 20.0 mA
Total of all pins
(When duty ≤ 70%
Note 3
)
50.0 mA
I
OL2 Per pin for P20 to P22, P155,
P156
0.4
Note 2
mA
Total of all pins
(When duty ≤ 70%
Note 3
)
2.0 mA
To Next Page
