Fax Connection Unit Type D (Remote Fax)
SM 13 D649
Fax Option
Type C305
(D649)
1.3 FAX CONNECTION UNIT TYPE D (REMOTE FAX)
1.3.1 INSTALLATION PROCEDURE
This unit allows a machine without the FAX unit installed (“Client-side Machine”) to send and
receive faxes via a machine with the FAX unit installed (“Remote Machine”).
1.3.2 REQUIREMENTS:
・ Both the Client-side Machine and Remote Machine must have this unit, the Printer unit, and
Scanner unit installed.
・
Up to six machines can be registered as the Client-side Machines.
・
Machines that have the FAX unit installed cannot be used as the Client-side Machine.
・
Only machine can be registered as the Remote Machine.
・
Firmware for this unit: “aics” （software number: D6575410）
・
Remote Fax transmissions are possible on a G3 line.
・ The remote fax function does not support User Code Authentication. Disable the User Code
Authentication on the Remote machine.
・ Use this function to check the contents of a file that is stored in memory and not yet sent. Also,
use this function to cancel a transmission from the Client-side Machine.
・ To use this remote fax function, both the main-machine and the sub-machines must have
HDD option.
Before installing this option:
Upgrade the machine firmware to the following versions or newer.
Firmware P/N Suffix Version
System/Copy D1175412 L 3.12
Fax D1175424 G 05.00.00
RemoteFax D1175425 D 02.00.00
Scanner D1175426 E 01.06
Websupport D1175427 F 1.05
WebUapl D1175428 C 1.02
Network Support D1175430 G 12.27
Network DocBox D1175431 E 2.01
Printer D1175432 F 1.06
PCL D1175434 D 1.08
Sub System D1175423 C F.12
FCU D6495570 G 05.00.00
⇒
Rev. 11/08/2012
