Bit Switches
D649 102 SM
4.3.5 G3 SWITCHES
G3 Switch 00 (SP No. 1-105-001)
No Function Comments
0
1
Monitor speaker during
communication (tx and rx)
(0, 0): The monitor speaker is disabled all
through the communication.
(0, 1): The monitor speaker is on up to
phase B in the T.30 protocol.
(1, 0): Used for testing. The monitor
speaker is on all through the
communication. Make sure that you reset
these bits after testing.
Bit 1 Bit 0 Setting
0 0 Disabled
0 1 Up to Phase B
1 0 All the time
1 1 Not used
2
Monitor speaker during memory
transmission
0: Disabled 1: Enabled
1: The monitor speaker is enabled during
memory transmission.
3-5 Not used Do not change the settings.
6
G3 mode selection for direct line
0: Off
1:On
1: G3 communication through the direct line
is enabled.
7 Not used Do not change the settings.
To Next Page
