SC Tables
D117/D118 6-14 SM
6.1.4 SC3XX: IMAGE PROCESSING – 1
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
312 D Charge P.P. output error: Bk
313 D Charge P.P. output error: Cy
314 D Charge P.P. output error: Ma
315 D Charge P.P. output error: Ye
The feedback voltage of the charge AC for each color is 0.3 V or less
for 0.2 seconds after the charge AC has turned on.
 Disconnected or broken harnesses of the HVPS
 Defective PCDU
 Defective HVPS
1. Check or replace the harnesses of the HVPS.
2. Reinstall or replace the PCDU.
3. Replace the HVPS.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
325 D
Color development motor error
The motor LOCK signal is not detected for more than two seconds
while the motor START signal is on.
 Color development motor slip due to an increase in the torque
caused by connected components
 Defective motor
1. Adjust the torque properly by replacing or cleaning the PCDU.
2. Replace the PCDU.
3. Replace the development motor: CMY if load torque is normal.
