Drive
SM 4-75 D117/D118
Replacement
and
Adjustment
4.10.8 DEVELOPMENT CLUTCH
1. Drum motor (K) ( p.4-67)
2. Development clutch with the cover [A] ( x 1, x 1, x 1)
3. Remove the development clutch from its cover [A].
