ARDF
D117/D118 4-152 SM
7. Bracket [A] (
x 2)
8. ARDF drive motor [A] ( x 2, x 1)
 Do not touch the encoder [B] when holding the motor.
4.16.10 WHITE PLATE
1. Open the ARDF.
2. White plate [A] (hook x 2)
