Service Tables
SM 55 D649
Fax Option
Type C305
(D649)
4.2.3 SP3-XXX (TEL LINE SETTINGS)
3
Mode No. Function
101
Service Station
001 Fax Number Enter the fax number of the service station.
002 Select Line Select the line type.
102
Serial Number
000 Enter the fax unit’s serial number.
103
PSTN-1 Port Settings
001 Select Line
Select the line type setting for the G3-1 line. If
the machine is installed on a PABX line, select
“PABX”, “PABX(GND)” or “PABX(FLASH)”.
002
PSTN Access
Number
Enter the PSTN access number for the
G3-1 line.
003
Memory Lock
Disabled
Not used
107
IPFAX Port Settings
001 H323 Port Sets the H323 port number.
002 SIP Port Sets the SIP port number.
003 RAS Port Sets the RAS port number.
004 Gatekeeper port Sets the Gatekeeper port number.
005 T.38 Port Sets the T.38 port number.
006 SIP Server Port Sets the SIP port number.
007
IPFAX Protocol
Priority
Select "H323" or "SIP".
201
FAX SW
001 – 032 00 – 1F
