Fax Connection Unit Type D (Remote Fax)
SM 15 D649
Fax Option
Type C305
(D649)
On the Client-side Machine(s):
1. Press the [User Tools/Counter] key on the operation panel
2. Press [Administrator Tools] to select.
3. Press [Program/Delete Device Certificate] to select.
4. Enter the IP address or host name of the Remote Machine and press [Set] to set.
5. Press [Exit] to exit from the set-up procedure.
Registering the Client-Side Machine(s)
 Up to six machines can be registered as the Client-side Machines.
On the Remote Machine:
1. Press the [User Tools/Counter] key on the operation panel
2. Press [Administrator Tools] to select.
3. Press [Program/Delete Device Certificate] to select.
4. Enter the IP address or host name of the Client-side Machines and press [Set] to set.
Configuring the Remote Reception Settings
Do the following procedure to enable the Client-side Machine(s) to receive faxes via the Remote
Machine. You can forward or route received documents per line or special sender or box.
 By performing procedures #1-3 above, the Client-side Machines can send faxes via
the Remote Machine. The procedures shown below are necessary to enable the
Client-side Machines to receive faxes.
On the Remote Machine:
1) If you use "Remote Reception Setting per Line"
1. Press [Facsimile Features] to select.
2. Press [Remote Reception Setting per Line] in [Reception Settings] to select.
3. Enter an IP address or a host name of the client-side machine to connect.
4. Press [Set], and [Exit] to exit from the setting.
Rev. 11/08/2012
