D117/D118 3-80 SM Appendix
2150
[Area Mag. Correction] LD Pulse Area Correction (Color, Area) FA
Adjusts the magnification for each area. The main scan (297 mm) is divided
into 13 areas. Area 1 is at the front side of the machine (left side of the image)
and area 13 is at the rear side of the machine (right side of the image).
Decreasing a value makes the image shift to the left side on the print.
Increasing a value makes the image shift to the right side on the print.
1 pulse = 1/16 dot
027 Area 0: Bk *ENG [-16.00 to 16.00 / 0.00 / 0.01dot/step]
028 Area 1: Bk *ENG [-16.00 to 16.00 / 0.20 / 0.01dot/step]
029 Area 2: Bk *ENG [-16.00 to 16.00 / -0.45 / 0.01dot/step]
030 Area 3: Bk *ENG [-16.00 to 16.00 / -0.62 / 0.01dot/step]
031 Area 4: Bk *ENG [-16.00 to 16.00 / -0.40 / 0.01dot/step]
032 Area 5: Bk *ENG [-16.00 to 16.00 / 0.00 / 0.01dot/step]
033 Area 6: Bk *ENG [-16.00 to 16.00 / 0.39 / 0.01dot/step]
034 Area 7: Bk *ENG [-16.00 to 16.00 / 0.56 / 0.01dot/step]
035 Area 8: Bk *ENG [-16.00 to 16.00 / 0.31 / 0.01dot/step]
079 Area 0: Ma *ENG [-16.00 to 16.00 / 0.00 / 0.01dot/step]
080 Area 1: Ma *ENG [-16.00 to 16.00 / 0.20 / 0.01dot/step]
081 Area 2: Ma *ENG [-16.00 to 16.00 / -0.45 / 0.01dot/step]
082 Area 3: Ma *ENG [-16.00 to 16.00 / -0.62 / 0.01dot/step]
083 Area 4: Ma *ENG [-16.00 to 16.00 / -0.40 / 0.01dot/step]
084 Area 5: Ma *ENG [-16.00 to 16.00 / 0.00 / 0.01dot/step]
085 Area 6: Ma *ENG [-16.00 to 16.00 / 0.39 / 0.01dot/step]
086 Area 7: Ma *ENG [-16.00 to 16.00 / 0.56 / 0.01dot/step]
087 Area 8: Ma *ENG [-16.00 to 16.00 / 0.31 / 0.01dot/step]
131 Area 0: Cy *ENG [-16.00 to 16.00 / 0.00 / 0.01dot/step]
