Bit Switches
D649 114 SM
IP Fax Switch 01 (SP No. 1-111-002)
No. Function Comments
0-3
IP Fax delay level setting
Selects the acceptable delay level.
Level 0 is the highest quality
Default is "0000" (level 0).
Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 0 Level 0
0 0 0 1 Level 1
0 0 1 0 Level 2
0 0 1 1 Level 3
4-7 IP Fax preamble wait time setting
Selects the preamble wait time.
[00 to 0f]
There are 16 values in this 4-bit binary
switch combination.
Waiting time: set value level x 100 ms
Max: 0f (1500 ms) Min: 00 (No wait time)
The default is "0000" (00H).
