SC Tables
SM 6-9 D117/D118
Troubleshooti
ng
6.1.3 SC 2XX: EXPOSURE
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
202
-01
D Polygon motor error 1: ON timeout: Bk, Cy
-03 D Polygon motor error 1: ON timeout: Ma, Ye
The polygon mirror motor does not reach the targeted operating speed
within the specified time after turning on or changing speed
ï‚§ Defective or disconnected harness to polygon motor driver board
ï‚§ Defective polygon motor driver board
ï‚§ Defective polygon motor
1. Replace the polygon motor.
2. Replace the laser optics housing unit.
3. Replace the harness.
4. Replace the BICU.
No. Type Details (Symptom, Possible Cause, Troubleshooting Procedures)
203
-01
D Polygon motor error 2: OFF timeout: Bk, Cy
-03 D Polygon motor error 2: OFF timeout: Ma, Ye
The polygon mirror motor does not leave the READY status within the
given time after the polygon motor switches off.
ï‚§ Disconnected or defective harness to polygon motor driver board
ï‚§ Defective polygon motor driver board
ï‚§ Defective polygon motor
1. Check or replace the harness.
2. Replace the polygon motor.
