6.3.17 IMAGE SKEW
Symptom Possible cause Necessary actions
Images are skewed
Incorrect installation of
paper
Install the paper correctly.
Incorrect paper guide
position
Adjust the paper guide
correctly.
 When adjusting the
paper width, use
the right side guide
only, with the green
clip. Do not hold
 the left side guide
at this time, or skew
will occur.
Defective registration roller Repair the paper feed unit.
Incorrect action of paper
transfer roller
Check the paper transfer
roller.
Defective BICU Replace the BICU.
Incorrect installation of
paper tray
Uninstall the paper tray units
and re-install them.
