Drive
SM 4-65 D117/D118
Replacement
and
Adjustment
4.10 DRIVE
4.10.1 DRIVE UNIT
1. Toner transport section ( p.4-49)
2. Drive unit [A] ( x 6)
4.10.2 PAPER TRANSPORT MOTOR
1. Fusing motor ( p.4-68)
2. Rear left handle [A] ( x 1)
