Main SP Tables-6
D117/D118 3-390 SM Appendix
6009
[ADF Free Run]
Performs a DF free run in simplex, duplex mode or stamp mode.
001 Simplex Mode ENG [0 or 1 / 0 / 1/step ]
002 Duplex Mode ENG [0 or 1 / 0 / 1/step ]
6017
[ADF Adjustment Magnification]
Adjusts the magnification in the sub-scan direction for the ARDF.
001 ADF Adjustment Magnification *ENG [-5.0 to 5.0 / 0 / 0.1 %/step]
6021 [ARDF Motor]
001 Gain selection *ENG
[0 to 2 / 0 / 1/step ]
0: Common
1: Only for GX060050
2: Only for GX060040
6800
[]
DFU
001 - CTL
[1 to 3 / 3/ 1/step ]
1: 1 pages
2: 2 pages
3: 3 pages
