Bit Switches
SM 85 D649
Fax Option
Type C305
(D649)
Printer Switch 01 (SP No. 1-103-002)
No Function Comments
0-2 Not used Do not change the settings.
3-4
Maximum print width used in
the setup protocol
These bits are only effective when bit 7 of the
printer switch 01 is “1”.
Bit 4 Bit 3 Setting
0 0 Not used
0 1 A3
1 0 B4
1 1 A4
5-6 Not used Do not change the settings.
7
Received message width
restriction in the protocol
signal to the sender
0: Disabled
1: Enabled
0: The machine informs the transmitting machine
of the print width depending on the paper size
available from the paper feed stations.
Refer to the table on the next page for how the
machine chooses the paper width used in the
setup protocol (NSF/DIS).
1: The machine informs the transmitting machine
of the fixed paper width which is specified by bits
3 and 4 above.
Relationship between available paper sizes and printer width used in the setup protocol
To Next Page
