Main SP Tables-6
SM Appendix 3-389 D117/D118
Appendix:
SP Mode
Tables
3.6 MAIN SP TABLES-6
3.6.1 SP6-XXX (PERIPHERALS)
6006 [ADF Adjustment]
001 Face *ENG [-2.0 to 2.0 / 0.0 / 0.1mm/step ]
002 Side-to-Side *ENG [-2.0 to 2.0 / 0.0 / 0.1mm/step ]
003 Leading Edge Duplex Front *ENG [-5.0 to 5.0 / 0.0 / 0.1mm/step ]
004 Leading Edge Duplex Rear *ENG [-5.0 to 5.0 / 0.0 / 0.1mm/step ]
007 Rear Edge Erase *ENG [-5.0 to 5.0 / 0.0 / 0.1mm/step ]
6007
[ADF INPUT Check]
Displays the signals received from the sensors and switches of the ARDF. Only
Bit 0 is used for ADF input check.
009 Original Detection ENG [0 or 1 / 0 / 1/step ]
013 Registration Sensor ENG [0 or 1 / 0 / 1/step ]
015 Feed Cover ENG [0 or 1 / 0 / 1/step ]
6008
[ADF OUTPUT Check]
Activates the electrical components for functional check.
It is not possible to activate more than one component at the same time.
003 Transport Motor:Forward ENG [0 or 1 / 0 / 1/step ]
004 Transport Motor:Reverse ENG [0 or 1 / 0 / 1/step ]
009 ADF:Feed:Solenoid ENG [0 or 1 / 0 / 1/step ]
011 ADF:Inverter Solenoid ENG [0 or 1 / 0 / 1/step ]
