SP Mode
Tables
2112
[TM/ID Sensor Test]
This SP is used to check the ID sensors at the factory. The results of this SP
are displayed in SP2140 to SP2145.
001 TM/ID Sensor Check ENG
[- / - / -]
[Execute]
010 General:FCRP *ENG [0 to 9999 / - / 1/step]
020 Threshold Setting *ENG [0.00 to 5.50 / 1.90 / 0.01V/step]
2117
[Skew Adjustment]
Specifies a skew adjustment value for the skew motor M, C, Y or Bk.
001 Ma:Skew Adjustment *ENG
[–256 to 256 / 0 / 1 click/step]
002 Cy:Skew Adjustment *ENG
003 Ye:Skew Adjustment *ENG
004 Bk:Skew Adjustment *ENG
2140
[TM/ID Sensor Check Result]
Displays the maximum result values of the ID sensor check.
Front, Center, Rear: ID sensors for the automatic line position adjustment and
the process control
001 PWM: ID Sensor *ENG
[0 to 1024 / - / 1/step]
005 PWM: Front *ENG
006 PWM: Center *ENG
007 PWM: Rear *ENG
