D117/D118 3-90 SM Appendix
017 M. Scan: High: Subdot: Y *ENG [-1.00 to 1.00 / 0.00 / 0.01dot/step]
020 M. Scan: Low: Dot: Y *ENG [-512 to 511 / 0 / 1dot/step]
021 M. Scan: Low: Subdot: Y *ENG [-1.00 to 1.00 / 0.00 / 0.01dot/step]
022 S. Scan: High: Line: M *ENG [-16384 to 16383 / 0 / 1line/step]
023 S. Scan: High: Subline: M *ENG [-1.00 to 1.00 / 0.60 / 0.01line/step]
026 S. Scan: Low: Line: M *ENG [-16384 to 16383 / 0 / 1line/step]
027 S. Scan: Low: Subline: M *ENG [-1.00 to 1.00 / 0 / 0.01line/step]
028 S. Scan: High: Line: C *ENG [-16384 to 16383 / 0 / 1line/step]
029 S. Scan: High: Subline: C *ENG [-1.00 to 1.00 / 0.20 / 0.01line/step]
032 S. Scan: Low: Line: C *ENG [-16384 to 16383 / 0 / 1line/step]
033 S. Scan: Low: Subline: C *ENG [-1.00 to 1.00 / 0.00 / 0.01line/step]
034 S. Scan: High: Line: Y *ENG [-16384 to 16383 / 0 / 1line/step]
035 S. Scan: High: Subline: Y *ENG [-1.00 to 1.00 / 0.60 / 0.01line/step]
038 S. Scan: Low: Line: Y *ENG [-16384 to 16383 / 0 / 1line/step]
039 S. Scan: Low: Subline: Y *ENG [-1.00 to 1.00 / 0.00 / 0.01line/step]
2185 [MUSIC Pattern Timing :Set]
001 Delay Time ENG [0 to 4000 / 0 / 1msec/step]
2190 [Line Position Adj.]
012 SnSErr Range *ENG [-3500 to 3500 / 0 / 1um/step]
2191
[MUSIC Coefficient Setting]
Position Adjustment: Coefficient Setting
ch 0: ID sensor at rear, ch 1: ID sensor at center, ch 2: ID sensor at front
001 ch 0: Filter: Front: a1 ENG [-131071 to 131071 / 125869 / 1bit/step]
To Next Page
