SP Mode
Tables
5307 [Summer Time]
001
Usable *CTL
[0 to 1 / - / 1/step]
0: Disabled
1: Enabled
(Default)
1: NA and EUR
0: ASIA and others
Enables or disables the summer time mode.
 Make sure that both SP5-307-3 and -4 are correctly set. Otherwise,
this SP is not activated even if this SP is set to "1".
003
start data set *CTL
[0 to 0xffffffff / - / 1hex/step]
(Default)
NA: 0x03200210
EUR: 0x03500010
ASIA: 0x10500010
Other: 0x00000000
Specifies the start setting for the summer time mode.
There are 8 digits in this SP. For months 1 to 9, the "0" cannot be input in the
first digit, so the eight-digit setting for -2 or -3 becomes a seven-digit setting.
1st and 2nd digits: The month. [1 to 12]
3rd digit: The week of the month. [1 to 5]
4th digit: The day of the week. [0 to 6 = Sunday to Saturday]
5th and 6th digits: The hour. [00 to 23]
7th digit: The length of the advanced time. [0 to 9 / 1 hour /step]
8th digit: The length of the advanced time. [0 to 5 / 10 minutes /step]
 The digits are counted from the left.
 Make sure that SP5-307-1 is set to "1".
For example: 3500010 (EU default)
The timer is advanced by 1 hour at am 0:00 on the 5th Sunday in March
