IP-Fax Troubleshooting
D649 48 SM
3.3.2 IP-FAX RECEPTION
Cannot receive via IP Address/Host Name.
Check Point Action
1 LAN cable connected? Check the LAN cable connection.
2 Firewall/NA T is installed?
Cannot breach the firewall. Send by using
another method (Fax, Internet Fax)
3 IP address of local fax registered? Register the IP address.
4
Port number specified at remote sender
fax (if required)?
Request the sender to specify the port
number.
5
Specified port number correct (if
required)?
Request the sender to check the port
number.
6
DNS server registered when host name
specified on sender side?
Contact the network administrator.
 The sender machine displays this
error code if the sender fax is a
Ricoh model.
7 Network bandwidth too narrow?
Request the system administrator to
increase the bandwidth.
Lower the start modem reception baud
rate on the receiving side.
IPFAX SW06
8 Remote fax cancelled transmission?
Check whether the remote fax cancelled
the transmission.
