Image Transfer
D117/D118 4-60 SM
4.8.4 ITB CONTACT SENSOR
1. ITB contact drive unit ( p.4-57 "ITB Contact Motor / Paper Transfer Contact Motor")
2. Sensor bracket [A] ( x 1, x 1)
3. ITB contact sensor [A] (Hook x 2)
