Main SP Tables-2
D117/D118 3-92 SM Appendix
027 ch 2: Filter: Rear: a2 ENG [-131071 to 131071 / -63398 / 1bit/step]
028 ch 2: Filter: Rear: b0 ENG [-131071 to 131071 / 84 / 1bit/step]
029 ch 2: Filter: Rear: b1 ENG [-131071 to 131071 / 168 / 1bit/step]
030 ch 2: Filter: Rear: b2 ENG [-131071 to 131071 / 84 / 1bit/step]
031 Q Format Selection ENG [0 to 3 / 3 / 1/step]
2192
[MUSIC Threshold Setting]
Line Position Adjustment: Threshold Setting
ch 0: ID sensor at rear, ch 1: ID sensor at center, ch 2: ID sensor at front
001 ch 0: 1st *ENG
[0.5 to 3.0 / 1.3 / 0.1V/step]
002 ch 0: 2nd *ENG
003 ch 0: 3rd *ENG
004 ch 0: 4th *ENG
005 ch 1: 1st *ENG
006 ch 1: 2nd *ENG
007 ch 1: 3rd *ENG
008 ch 1: 4th *ENG
009 ch 2: 1st *ENG
010 ch 2: 2nd *ENG
011 ch 2: 3rd *ENG
012 ch 2: 4th *ENG
