Main SP Tables-3
D117/D118 3-190 SM Appendix
3031 [TD Sens Init OK?]
001 From Left:YMCK *ENG
Displays the execution result of TD
sensor initialization.
[0 to 9999 / - / 1/step]
3050 [Force Tnr Supply:Exe]
001 Execute:ALL ENG
[- / - / -]
[Execute]
002 Execute:Col ENG
[- / - / -]
[Execute]
003 Execute:K ENG
[- / - / -]
[Execute]
004 Execute:C ENG
[- / - / -]
[Execute]
005 Execute:M ENG
[- / - / -]
[Execute]
006 Execute:Y ENG
[- / - / -]
[Execute]
021 Supply Quantity:K *ENG
[0.0 to 5.0 / 0.5 / 0.1wt%/step]
022 Supply Quantity:C *ENG
023 Supply Quantity:M *ENG
024 Supply Quantity:Y *ENG
031 ON Time *ENG [10 to 1000 / 200 / 1msec/step]
032 OFF Time *ENG [0 to 1000 / 100 / 1msec/step]
033 RepeatCount *ENG [0 to 255 / 8 / 1times/step]
