Main SP Tables-2
D117/D118 3-86 SM Appendix
060 Area 11: Ye *ENG [1 to 63 / 5 / 1/step]
2154
[Outside Shad. Correct Setting]
Sets the adjust coefficient for outside the exposure shading for each color in
each area of the MUSIC pattern.
001
Front Beam Detecting Area:
Bk
*ENG [50 to 150 / 100 / 1%/step]
003 Front End Area: Bk *ENG [50 to 150 / 105 / 1%/step]
004
Front Beam Detecting Area:
Ma
*ENG [50 to 150 / 100 / 1%/step]
006 Front End Area: Ma *ENG [50 to 150 / 105 / 1%/step]
007
Front Beam Detecting Area:
Cy
*ENG [50 to 150 / 100 / 1%/step]
009 Front End Area: Cy *ENG [50 to 150 / 105 / 1%/step]
010
Front Beam Detecting Area:
Ye
*ENG [50 to 150 / 100 / 1%/step]
012 Front End Area: Ye *ENG [50 to 150 / 105 / 1%/step]
