D117/D118 6-2 SM
After you turn the main power switch off, wait for one second or more before you turn the main
power switch on (SC 672). All SCs are logged. The print log data (SP5-990-004) in SP mode can
check the latest 10 SC codes detected and total counters when the SC code is detected.
 If the problem concerns electrical circuit boards, first disconnect then reconnect the
connectors before you replace the PCBs.
 If the problem concerns a motor lock, first check the mechanical load before you replace
motors or sensors.
SC Code Classification
The table shows the classification of the SC codes:
Class 1 Section SC Code Detailed section
1XX Scanning
100 - Scanner
190 - Unique for a specific model
2XX Exposure
200 - Polygon motor
220 - Synchronization control
230 - FGATE signal related
240 - LD control
280 - Unique for a specific model
290 - Shutter
3XX Image Processing 1
300 - Charge
330 - Drum potential
350 - Development
380 - Unique for a specific model
