Controller Options
SM 2-89 D117/D118
Installation
Undo Exec
"Undo Exec" (SP5-873-002) lets you move back application programs from an SD card in SD
Card Slot 1 (upper) to the original SD card in SD Card Slot 2 (lower). You can use this program
when, for example, you have mistakenly copied some programs by using Move Exec
(SP5-873-001).
Do not turn ON the write protect switch of the system SD card or application SD card on
the machine. If the write protect switch is ON, a download error (e.g. Error Code 44)
occurs during a firmware upgrade or application merge.
1. Turn the main switch off.
2. Insert the original SD card in SD Card Slot 2 (lower). The application program is copied back
into this card.
3. Insert the SD card with the application program in SD Card Slot 1 (upper).The application
program is copied back from this SD card.
4. Turn the main switch on.
5. Start the SP mode.
6. Select SP5-873-002 "Undo Exec."
7. Follow the messages shown on the operation panel.
8. Turn the main switch off.
9. Remove the SD card from SD Card Slot 2 (lower).
10. Turn the main switch on.
11. Check that the application programs run normally.
12. Make sure that the machine can recognize the option (see “Check All Connections” at the end
of this section).
